Steel Fuel Cell Filler Neck with Aluminum Cap — 45° Angle Black
45-degree angled filler neck in steel with a machined aluminum cap for custom fuel cell installations. Built for welding into aftermarket fuel cells where a clean, controlled fill point is non-negotiable. The angle allows practical fill access without interference on tight engine bays.
Key Features
- 45-degree angle design - Clears headers and manifolds on tight installs where vertical necks won't fit.
- Aluminum cap - Corrosion-resistant, lightweight, and easier to machine for custom venting or overflow lines.
- Steel body - Weld-in construction rated for fuel cell durability and vibration resistance.
Specs
- Material: Steel body with aluminum cap
- Angle: 45 degrees
- Finish: Black
- Installation: Weld-in design
What's Included
- Filler neck assembly with aluminum cap
Frequently Asked Questions
Does this neck require any prep work before welding?
Clean the mounting area on your fuel cell with a wire brush to remove any oil or mill scale before welding. The neck itself arrives ready to weld — no additional machining or coating needed.
Can I use this with an aftermarket fuel cell overflow or vent system?
Yes. The aluminum cap is straightforward to drill or machine if you need to plumb a secondary vent line or overflow return. Work out your fuel system layout before final welding so you know exactly where to open it.
Will the 45-degree angle fit my engine bay layout?
The angle is designed to clear headers and tight installations where a vertical neck doesn't work. Measure your available space and test-fit before committing the neck to the cell — engine bay geometry varies significantly between builds.
